Allocation of the program of script development model in URL¶

• http://<HOST>:<PORT>/<CONTEXT_PATH>/app/foo creates the routing table that allocates the path of Script Development Model in business/foo.

  • Presentation Page

    Create the file in <CONTEXT_PATH>/WEB-INF/jssp/src/business/foo.html.

    File contains the following.

    This is foo.


  • Function Container

    Do not create the function container since the process does not exist.

  • Routing Table

    Create the file in <CONTEXT_PATH>/WEB-INF/conf/routing-jssp-mapping/routing-programming-guide-foo.xml.

    File contains the following.

    <?xml version="1.0" encoding="UTF-8"?>
    <routing-jssp-config
        xmlns="http://www.intra-mart.jp/router/routing-jssp-config"
        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:schemaLocation="http://www.intra-mart.jp/router/routing-jssp-config routing-jssp-config.xsd">

        <authz-default mapper="welcome-all" />

        <file-mapping path="/app/foo" page="business/foo" />

    </routing-jssp-config>


    Carry out the program mapping of Script Development Model and URL with file-mapping elements.

    Specify path /app/foo of URL in path attribute, path business/foo of Script Development Model in page attribute.

• Restart the application server in order to reflect the configuration file.

• Access http://<HOST>:<PORT>/<CONTEXT_PATH>/app/foo.

  Page displays the following.

  This is foo.


  Note

  The following points were confirmed in this item.

  • Program allocation of Script Development Model to URL is carried out using file-mapping elements.
  • Describe the URL path in path attribute of file-mapping element and path of Script Development Model in page attribute.

PathVariables¶

• http://<HOST>:<PORT>/<CONTEXT_PATH>/app/bar/{id} creates the routing table allocated to path business/bar of Script Development Model .

  • Presentation Page

    Create the file in <CONTEXT_PATH>/WEB-INF/jssp/src/business/bar.html.

    File contains the following.

    "id" is <imart type="string" value=id />.


  • Function Container

    Create the file in <CONTEXT_PATH>/WEB-INF/jssp/src/business/bar.js.

    File contains the following.

    var id;

    function init(request) {
        id = request.id;
    }


  • Routing Table

    Create the file in <CONTEXT_PATH>/WEB-INF/conf/routing-jssp-mapping/routing-programming-guide-bar.xml.

    File contains the following.

    <?xml version="1.0" encoding="UTF-8"?>
    <routing-jssp-config
        xmlns="http://www.intra-mart.jp/router/routing-jssp-config"
        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:schemaLocation="http://www.intra-mart.jp/router/routing-jssp-config routing-jssp-config.xsd">

        <authz-default mapper="welcome-all" />

        <file-mapping path="/app/bar/{id}" page="business/bar" />

    </routing-jssp-config>


    The value in the URL is delivered as the parameter by mentioning as a {[Identifier]} in path attribute.

• Restart the application server in order to reflect the configuration file.

• Access http://<HOST>:<PORT>/<CONTEXT_PATH>/app/bar/aoyagi.

  Page displays the following.

  "id" is aoyagi.


• Access http://<HOST>:<PORT>/<CONTEXT_PATH>/app/bar/ueda.

  Page displays the following.

  "id" is ueda.


  Note

  The following points were confirmed in this item.

  • The value in the URL is used as the request parameter by describing as a {[Identifier]} in path attribute of file-mapping element.

Authorization¶

<?xml version="1.0" encoding="UTF-8"?>
<routing-jssp-config
    xmlns="http://www.intra-mart.jp/router/routing-jssp-config"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://www.intra-mart.jp/router/routing-jssp-config routing-jssp-config.xsd">

    <authz-default mapper="welcome-all" />

    <file-mapping path="/app/foo" page="business/foo" />

    <file-mapping path="/app/baz" page="business/baz">
        <authz uri="service://app/baz" action="execute" />
    </file-mapping>

</routing-jssp-config>

welcome-all resource mapper is specified in authz-default element. This authorized resource mapper is used during the development. At the time of application release, specifying the appropriate uri and action or mapper is highly recommended.

When accessing /app/xxx, since authz element does not exist in file-mapping element, welcome-all mapper which is the default authorization setting, becomes effective as the authorization setting.

When accessing /app/baz, since authz element exists in file-mapping element, service://app/baz is enabled as authorization setting for uri, and execute is enabled as authorization setting for action.

authz-default element and authz element can be omitted. However, when the valid authorization setting for file-mapping is not specified, setting error is returned.

In menu items, only the privileged items for URL to be accessed are displayed.

Refer to Authorization for the details.

Note

The following points were confirmed in this item.

• Authorization setting can be done using authz-default element and authz element.
• Setting error is returned when authorization setting is not done for URL.

Client Type¶

• When accessed from http://<HOST>:<PORT>/<CONTEXT_PATH>/app/qux smartphone, allocate to path business/qux_sp of Script Development Model and when accessed from the other terminal, create routing table allocated to business/qux.

  • Presentation page for smartphone

    Create file in <CONTEXT_PATH>/WEB-INF/jssp/src/business/qux_sp.html.

    File contains the following.

    Smartphone.


  • Creation of the presentation page when accessed except from smartphone

    Create file in <CONTEXT_PATH>/WEB-INF/jssp/src/business/qux.html.

    File contains the following.

    Not smartphone.


  • Function Container

    Do not create the function container since the process does not exist.

  • Routing Table

    Create the file in <CONTEXT_PATH>/WEB-INF/conf/routing-jssp-mapping/routing-programming-guide-qux.xml.

    File contains the following.

    <?xml version="1.0" encoding="UTF-8"?>
    <routing-jssp-config
        xmlns="http://www.intra-mart.jp/router/routing-jssp-config"
        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:schemaLocation="http://www.intra-mart.jp/router/routing-jssp-config routing-jssp-config.xsd">

        <authz-default mapper="welcome-all" />

        <file-mapping path="/app/qux" page="business/qux" />

        <file-mapping path="/app/qux" page="business/qux_sp" client-type="sp" />

    </routing-jssp-config>


    Mapping of the specified client type can be set by specifying the client-type attribute in file-mapping element.

• Restart the application server in order to reflect the configuration file.

• Access http://<HOST>:<PORT>/<CONTEXT_PATH>/app/qux with the PC browser.

  Page displays the following.

  Not smartphone.


• Access http://<HOST>:<PORT>/<CONTEXT_PATH>/app/qux with the smartphone browser.

  Page displays the following. .. literalinclude:: include/qux_sp.jssp :language: html
  • Access http://<HOST>:<PORT>/CONTEXT_PATH>/menu/sitemap when there is no smartphone device that can access server. After that, select “Smartphone” of utility menu at the right top and access the URL.



  Note

  The following points were confirmed in this item.

  • Program of Script Development Model of the specific client type can be specified by specifying the client-type attribute in file-mapping element.
